RF Instruments, we are recognized as one of the industry’s leading suppliers of advanced RF test equipment and related communication solutions. Our consistent track record for quality and service has established us as a reliable partner and trusted provider in the field.
SA series from HAROGIC is designed for compact USB real-time spectrum analyzer. Based on SWaP-C and self-develop filters, the weight and size for SA series up to 40 GHz is compatible with a smart phone, suitable for embedded RF system and portable RF measurement. SA models are equipped with highly compatible APIs, empowering customers to develop their own RF system via second development.
- 9 kHz~40 GHz real-time spectrum analyzer/receiver;
- Superheterodyne digital receiver architecture, 14 segments pre-selected filter;
- Typical image suppression and IF rejection>75 dBc;
- 100 MHz analysis bandwidth with adjustable sampling rate, 400 GHz/sec spectrum sweep speed;
- FPGA based digital signal processing;
- 40 GHz DANL=-141 dBm/Hz, Phase Noise=-86 dBc/Hz@10 kHz;
- 9 kHz~20 GHz real-time spectrum analyzer/receiver
- Superheterodyne digital receiver architecture, 19segments pre-selected filter
- 9 kHz~9 GHz typical image suppression>90 dB, typical IF rejection>90 dB
- 9 GHz~20 GHz typical image suppression>60 dB, typical IF rejection>90 dB
- 100 MHz analysis bandwidth with adjustable sampling rate, 1.2 THz/sec spectrum sweep speed
- FPGA based digital signal processing
- 9 kHz~9.5 GHz real-time spectrum analyzer/receiver
- Superheterodyne digital receiver architecture, 14segments pre-selected filter
- 9 kHz~9.5 GHz typical image suppression>90 dB, typical IF rejection>90 dB
- 100 MHz analysis bandwidth with adjustable sampling rate, 1.2 THz/sec spectrum sweep speed
- FPGA based digital signal processing
- 9 kHz~8.5 GHz real-time spectrum analyzer/receiver
- Integrated 100 kHz-6.3 GHz analog signal generator (option)
- 100MHz analysis bandwidth, 300 GHz/sec spectrum sweep speed
- FPGA based digital signal processing
- 9 kHz~6.3 GHz real-time spectrum analyzer/receiver
- Integrated 100 kHz-6.3 GHz analog signal generator (option)
- 100 MHz analysis bandwidth, 300 GHz/sec spectrum sweep speed
- FPGA based digital signal processing
- 9 kHz~6.3 GHz real-time spectrum analyzer
- Integrated 100 kHz-6.3 GHz analog signal generator (option)
- 25 MHz analysis bandwidth, 100 GHz/s sweep speed, FPGA signal processing
- Typical phase noise: 1GHz carrier -110 dBc/Hz@10 kHz
- Standard preamplifier, DANL: -162 dBm/Hz
- 9 kHz~4.5/6.3 GHz real-time spectrum analyzer/receiver
- Integrated 100 kHz-6.3 GHz analog signal generator (option)
- Equipped with preamplifier, DANL: -160 dBm/Hz, residual response: -110dBm
- Typical phase noise: -110 dBc/Hz@1 GHz 10 kHz offset
- Bandwidth: 6.25 MHz, spectrum sweep speed> 20 GHz/s
NX series is a miniaturized network node real-time spectrum analyzer based on 1 GbE Ethernet interface and high-speed FPGA signal processing. NX model is with compact design but not simple, the RF front end contains a complete preamplifier, attenuator, multi-segment preselector. It is able to output spectrum, digital IQ stream, power detection and real-time spectrum.
- 9 kHz-40 GHz real-time spectrum analyzer
- Superheterodyne digital receiver architecture, 14 segments pre-selected filter
- 9 kHz~40 GHz typical image suppression >75 dBc, typical IF rejection>75 dBc
- 100 MHz analysis bandwidth with adjustable sampling rate, 291.6 GHz/sec sweep speed
- FPGA based digital signal processing
- 9 kHz-20 GHz real-time spectrum analyzer/receiver
- Superheterodyne digital receiver architecture, 19 segments pre-selected filter
- 9 kHz-9 GHz typical image suppression>90 dB, typical IF rejection>90 dB
- 9 GHz~20 GHz typical image suppression>60 dB, typical IF rejection>90 dB
- 100 MHz analysis bandwidth with adjustable sampling rate, 320.2 GHz/sec sweep speed
- FPGA based digital signal processing
- 9 kHz-9.5 GHz real-time spectrum analyzer/receiver
- Superheterodyne digital receiver architecture, 14segments pre-selected filter
- 9 kHz-9.5 GHz typical image suppression>90 dB, typical IF rejection>90 dB
- 100 MHz analysis bandwidth with adjustable sampling rate, 330.9 GHz/sec sweep speed
- FPGA based digital signal processing
- 9 kHz-6.3 GHz real-time spectrum analyzer
- Integrated 100 kHz-6.3 GHz analog signal generator (option)
- DANL: -160 dBm/Hz, residual response: -110 dBm, equipped with preamplifier
- 1GHz phase noise: -110 dBc/Hz@10 kHz offset
- 6.25 MHz analysis bandwidth, 69 GHz/s spectrum sweep speed
- 9 kHz-6.3 GHz real-time spectrum analyzer/receiver
- Integrated 100 kHz-6.3 GHz analog signal generator (option)
- 100MHz analysis bandwidth, 78 GHz/sec spectrum sweep speed
- FPGA based digital signal processing
- 9 kHz-4.5 GHz real-time spectrum analyzer
- Integrated 100 kHz-6.3 GHz analog signal generator (option)
- Equipped with preamplifier, DANL: -160 dBm/Hz, residual response: -110 dBm
- 1GHz phase noise: -110 dBc/Hz@10 kHz offset
- Bandwidth: 6.25 MHz, spectrum sweep speed> 69 GHz/s
PX series is the handheld real-time spectrum analyzer with 10.1-inch full touch screen and typical standby time of more than 3 h. The weight of PX model is only 1.5 kg but it covers frequency range from 9 kHz to 40 GHz, analysis bandwidth up to 100 MHz and sweep speed of up to 900 GHz/s. PX model is equipped with a standard preamplifier and used in a wide range of scenarios, such as spectrum analysis, phase noise, zero span, OBW, analog demodulation, digital demodulation. It provides engineers with a precise and reliable RF analyzer.
- Frequency range: 9kHz to 40GHz
- 1 GHz DANL: -161 dBm/Hz
- 1 GHz phase noise: -107 dBc/Hz@10 kHz
- Analysis Bandwidth: up to 100 MHz
- Portable makes possible
- 1.5 kg lightweight, 10.1-inch multi touchscreen
- Frequency range: 9kHz to 20GHz
- Superheterodyne receiver structure, 19-segment preselected filtering
- Display average noise level as low as -168dBm/Hz, standard preamplifier
- Spectrum scanning rate up to 900GHz/s (RBW≥300kHz)
- Single sideband phase noise: -100 dBc/Hz @1GHz, 10kHz offset
- Standard analysis bandwidth 100MHz
- Frequency range: 9 kHz to 9.5/20 GHz
- 1 GHz DANL: -168 dBm/Hz
- 1 GHz phase noise: -100 dBc/Hz@10 kHz
- Analysis Bandwidth: up to 100 MHz
- Channel power, phase noise and more
- 3 hours operation time
- Portable makes possible
- 1.5 kg lightweight, 10.1-inch multi touchscreen
HAROGIC PXN-400Z handheld spectrum analyzer is up to 40 GHz with 100 MHz bandwidth. It is the latest spectrum analyzer based on Windows 11 operating system and AMD Z1 extreme CPU for effective field computing analysis.
- Windows 11 operating system
- 1.2 kg lightweight, 8.8-inch multi touchscreen
- Frequency range: 9 kHz to 40 GHz
- 1 GHz DANL: -168 dBm/Hz
- 1 GHz phase noise: -100 dBc/Hz@10 kHz
- Analysis bandwidth: up to 100 MHz
- CPU: high performance AMD Z1 Extreme
- 16 GB RAM and 512 GB SSD
- Windows 11 operating system
- 1.2 kg lightweight, 8.8-inch multi touchscreen
- Frequency range: 9 kHz to 20 GHz
- 1 GHz DANL: -168 dBm/Hz
- 1 GHz phase noise: -100 dBc/Hz@10 kHz
- Analysis bandwidth: up to 100 MHz
- CPU: high performance AMD Z1 Extreme
- 16 GB RAM and 512 GB SSD
- Windows 11 operating system
- 1.2 kg lightweight, 8.8-inch multi touchscreen
- Frequency range: 9 kHz to 9.5 GHz
- 1 GHz DANL: -168 dBm/Hz
- 1 GHz phase noise: -100 dBc/Hz@10 kHz
- Analysis bandwidth: up to 100 MHz
- CPU: high performance AMD Z1 Extreme
- 16 GB RAM and 512 GB SSD
HAROGIC PXR series is the latest rugged handheld spectrum analyzer with IP68 standard design. With its IP68-rated enclosure, it delivers unparalleled durability, ensuring reliable performance in extreme conditions—dust, water, and shock. Featuring frequency range of 9 kHz to 40 GHz and an analytical bandwidth of 100 MHz, the PXR series handheld rugged spectrum analyzer guarantees reliable and accurate measurement anywhere and anytime.
- IEC IP68 certified
- MIL-STD-810H method-512.6/514.8/516.8 certified
- 2.5 kg lightweight, 10.1-inch multi touchscreen
- Frequency range: 9 kHz to 40 GHz
- 1 GHz DANL: -161 dBm/Hz
- 1 GHz phase noise: -100 dBc/Hz@10 kHz
- Analysis bandwidth: up to 100 MHz
- Operation Time: 4 Hours (typ.)
- IEC IP68 certified
- MIL-STD-810H method-512.6/514.8/516.8 certified
- 2.5 kg lightweight, 10.1-inch multi touchscreen
- Frequency range: 9 kHz to 20 GHz
- 1 GHz DANL: -161 dBm/Hz
- 1 GHz phase noise: -100 dBc/Hz@10 kHz
- Analysis bandwidth: up to 100 MHz
- Operation Time: 4 Hours (typ.)
- IEC IP68 certified
- MIL-STD-810H method-512.6/514.8/516.8 certified
- 2.5 kg lightweight, 10.1-inch multi touchscreen
- Frequency range: 9 kHz to 9.5 GHz
- 1 GHz DANL: -161 dBm/Hz
- 1 GHz phase noise: -100 dBc/Hz@10 kHz
- Analysis bandwidth: up to 100 MHz
- Operation Time: 4 Hours (typ.)
- Frequency Range: 500 MHz to 10 GHz
- Directional Radiation Pattern, Passive Gain: 5 dBi
- Typical Noise Figure (NF): ≤ 1.5 dB
- Compatible with all HAROGIC Spectrum Analyzers, Automatic Antenna Factor Loading
- Total Weight: 680 g, Compact and Portable
- Ergonomic Design, Suitable for Extended Outdoor Use
